Product center >> General-purpose industrial pump seal

MG12,MG13 Mechanical seal

Model Series: MG12/12-Z, MG12/14-Z, MG12/16-Z, MG12/18-Z,
                   MG12/20-Z, MG12/22-Z, MG12/24-Z, MG12/25-Z, MG12/28-Z, MG12/30-Z,
                   MG12/32-Z, MG12/33-Z, MG12/35-Z, MG12/38-Z, MG12/40-Z, MG12/42-Z,
                   MG12/43-Z, MG12/45-Z, MG12/48-Z, MG12/50-Z, MG12/53-Z, MG12/55-Z,
                   MG12/58-Z, MG12/60-Z, MG12/65-Z, MG12/68-Z, MG12/70-Z, MG12/75-Z,

                   MG13/20-Z, MG13/22-Z, MG13/24-Z, MG13/25-Z, MG13/28-Z, MG13/30-Z,
                   MG13/32-Z, MG13/33-Z, MG13/35-Z, MG13/38-Z, MG13/40-Z, MG13/42-Z,
                   MG13/43-Z, MG13/45-Z, MG13/48-Z, MG13/50-Z, MG13/53-Z, MG13/55-Z,
                   MG13/58-Z, MG13/60-Z, MG13/65-Z, MG13/68-Z, MG13/70-Z, MG13/75-Z,
    Structural features: Single seal, non-equilibrium type, rotation, lug gear, rubber bellows, split.
    Application: used in a variety of water, sewage, oil circulation pump.
    Operating parameters: pressure: ≤ 1.2 MPa Temperature: -20 ~ 120 ℃ Speed: ≤ 12m / s
